X-360M en Louisville, Misisipi, USA
Usado
Doubleclick to zoom in
Contacte al vendedor
para más fotos y información.
Especificaciones
- Condición
- usado
- Transmisión
- TE-14 4-sp. Powershift
- Mástil
- 11 UV
- Carruaje
- C-84
- Tenedores
- 3.5x8x48 in
- Frenos
- Hidráulico
- Voltios
- 24
- Neumáticos
- 12.00 x 20 - 24PR
- Categoría
- Carretillas elevadoras en USA
- Subcategoría
- Maquinaria
- Subcategoría 2
- Montacargas con neumáticos
- ID de Anuncio
- 107045143
Descripción
11-ft ULTRA-VU 2-Stage Mast (143-in lowered height)
84-in pin-type “C” carriage
3.5-in X 8-in X 48-in pin mounted forks
Motor diesel Cummins QSB 6.7L 173Hp Tier-4 Final
Donaldson dry-type air cleaner w/safety element & restriction indicator (vertical air intake extension with TaylorMax Precleaner)
Dana TE-14 4-speed powershift transmission
Powertrain Protection System for engine and transmission
Kessler D-81 planetary drive axle with wet disc brakes
Taylor 300 welded steel steer axle (single hydraulic cylinder design with heavy-duty links from the cylinder ram directly to tapered roller bearing mounted spindles)
12.00 X 20 – 24PR bias pneumatic drive and steer tires
All-welded steel frame with 4 lifting eyes (lifting eyes not designed for level pick)
Bolted counterweight
Replaceable bolt-on steps and handrails
Lockable Fuel Cap
Hinged engine hood, side service doors and removable floor panels open to expose drive train for ease of maintenance.
